| Polyrib polypropylene is a crystalline polymer noted for excellent chemical resistance. It is used extensively in chemical processing, chemical storage, metal finishing, electroplating, galvanizing industry. It is also used to make engineering components such as nozzles, impellers, pumps casing jigs & fixtures. It find extensive use in orthopaedic and prosthetic devices and semi conductors and clean room industry. It is being used to make components and consumer articles via vacuum and thermoforming process. |
 |
 |
| |
| |
|
| |
| ADVANTAGES: |
 |
Low Density. |
| |
|
High Strenght to weight ratio
|
| |
|
Excellent chemical and corrosion resistance |
| |
|
Excellent Vacuum thermoforming properties |
| |
|
Corrosion Resistance |
| |
|
Cost Effectiveness |
| |
|
Very good welding and machine property |
| |
|
| |
 |
|
| DELIVERY PROGRAMME: |
| POLYRIB PPX 258 |
|
PHomopolymer for tanks/vessels
|
| POLYRIB PPX 259 |
|
Block copolymer with high strength |
| POLYRIB PP GL |
|
PP fibre glass lined |
| POLYRIB HITECH * |
|
High heat & chemical resistant grade for tanks
& vessels |
| POLYRIB HITECH GL |
|
High heat & chemical resistant PP GL backed |
| POLYRIB PIPLA |
|
Cutting boards |
| DIPRA AD CLEAR |
|
Glow sign sheet for advertising |
| DIPRA CLEAR |
|
Transparent clean sheet |
| POLYRIB PP EMBOSSES |
|
One side embossed sheet |
| POLYRIB PP DUAL |
|
Co-extruded double coloured |
| POLYRIB PP-R |
|
Random copolymer |
| POLYRIB HITECH-M |
|
Stabilised against contact |
| POLYRIB PPUV |
|
UV Stabilised polypropylene |
| |
|
|
| |
 |
STANDARD SIZES: |
 |
|
| |
| PRESSED SHEETS: |
| Width |
 |
Width |
|
Thickenss |
| 1230 |
1230 |
8 mm 100 mm
|
| 1230 |
1230 |
8 mm 100 mm |
|
| |
|
|
| Extruded Sheets: |
Width
|
|
Length
|
|
Thickenss |
| 1250 |
2000 |
1.0 mm to 20 mm |
| 1220 |
2440 |
0.5 mm to 20 mm |
| 1000 |
2000 |
0.5 mm to 30 mm |
| 1000 |
3000 |
0.5 mm to 30 mm |
| 1000 |
4000 |
0.5 mm to 30 mm |
|
|
|
| Extruded Sheets: |
Width
|
|
Length
|
|
Thickenss
|
| 1350 |
10,000 |
1.5 mm to 5 mm PPGl |
| 1220 |
30,500 |
1.0 mm to 2 mm
DIPRA Add clear |
| 1220 |
10,000 |
0.5 mm to 5 mm PP
sheets |
|
|
|
|
| |
| |
|
| |
Extruded Rods: |
| |
|
| |
10mm – 300 mm dia of standard length 0f 1 metre.
Special colors are Available on requests. |
|
| |
 |
| |
| TECHNICAL DATA |
|
|
|
|
|
|
| Property |
Test method |
Unit |
KBK PP
HP |
| Density |
ISO 1183 |
g/cm3 |
0.9 |
| Molecular |
- |
Mil/mol |
- |
| Tensile strength |
ISO 527-1 |
Mpa |
34 |
| Breaking strength |
ISO 527-1 |
Mpa |
- |
| Elongation At Break |
ISO 527-1 |
% |
9 |
| Modulus of elasticity |
ISO 527-1 |
Mpa |
1300 |
| Imapact strength |
ISO 179
|
Kj/m2 |
NB |
Imapact strength 15 ° V Notch
|
ISO 179 |
Kj/m2 |
6 |
| Ball thrust hardness 30s |
ISO 2039.1 |
N/mm2 |
65 |
| Shore Hardness D 15 s |
ISO 868 |
- |
72 |
| Wear Resistance |
Sand slurry |
- |
400-500 |
Vicat softening temp. VSP/b/50
|
ISO 306 |
°C |
90 |
| |
|
|
|
|
|
|
|
| |
| |
